Standard Terminal Enclosure |
49
|
Standard Terminal Enclosure |
| MODEL NO. | KW 1 or 3 PHASE |
DIMENSIONS (INCHES) | FLANGE SIZE |
|||
| 208 VOLT | 240 VOLT | 480 VOLT | Aħ1 | Bħ1 | ||
| PFS-3023-3 PFS-6023-3 PFS-9023-3 |
PFS-3043-3 PFS-6043-3 PFS-9043-3 |
PFS-3053-3 PFS-6053-3 PFS-9053-3 |
3 6 9 |
25 42-1/2 57-1/2 |
20-1/2 38 53 |
3 3 3 |
| PFS-12026-5 PFS-15026-5 PFS-18026-5 |
PFS-12046-5 PFS-15046-5 PFS-18046-5 |
PFS-12056-5 PFS-15056-5 PFS-18056-5 |
12 15 18 |
42-1/2 50 57-1/2 |
38 45-1/2 53 |
5 5 5 |
| PFS-20026-5 PFS-25029-5 PFS-30029-5 |
PFS-20046-5 PFS-25049-5 PFS-30049-5 |
PFS-20056-5 PFS-25059-5 PFS-30059-5 |
20 25 30 |
64 57-1/2 64-1/2 |
59-1/2 53 60 |
5 5 5 |
| PFS-90212-6 PFS-120212-6 |
PFS-400412-5 PFS-90412-6 PFS-120412-6 |
PFS-400512-5 PFS-90512-6 PFS-120512-6 |
40 9 12 |
64-1/2 20-1/2 25-1/2 |
60 16 21 |
5 6 6 |
| PFS-180212-6 PFS-200212-6 |
PFS-180412-6 PFS-200412-6 |
PFS-180512-6 PFS-200512-6 |
18 20 |
33 35-1/2 |
28-1/2 31 |
6 6 |
| PFS-240212-6 |
PFS-240412-6 PFS-300412-6 |
PFS-240512-6 PFS-300512-6 |
24 30 |
43 50-1/2 |
38-1/2 46 |
6 6 |
| |
PFS-360412-6 PFS-300418-8 |
PFS-360512-6 PFS-300518-8 |
36 30 |
58 36-5/8 |
53-1/2 32 |
6 8 |
| |
PFS-400418-8 PFS-500418-8 PFS-600418-8 |
PFS-400518-8 PFS-500518-8 PFS-600518-8 |
40 50 60 |
45-5/8 57-5/8 64-5/8 |
41 53 60 |
8 8 8 |
| |
PFS-700418-8 PFS-800418-8 |
PFS-700518-8 PFS-800518-8 |
70 80 |
73-5/8 83-1/8 |
69 78-1/2 |
8 8 |
