TECHNICAL INFORMATION

GRAPH 6

SUGGESTED WATT DENSITY FOR GAUGE PRESSURE 50 TO 150 POUNDS STEAM & AIR TEMPERATURE Velocity Ft. Per Sec. 1 10 20 300° F. 20 27 30 500° F. 17 24 27 700° F. 13 17 20
